Key Features

Shorter warm up time and print speed of 23.4M/min. on tack paper
Long continuous printing up to 1,000m
Over printing capability with accurate registration
Compact footprint
Space saving integrated design


− Close All + Expand All
Enhanced productivity

Print speed up to 23.4m/min, faster turnaround time and helps to expand the printing business

Improved overall productivity

Short warm-up time from job to next job is minimised by no turning off of fusing unit., also minimise the paper waste

Better to environment

Reduced waste resulting from sophisticated color adjustment features


Small to mid volume label printer to suit a variety of markets and applications

Easy operation and maintenance

Operation is intuitive by following on-screen instructions; no need for extensive user training

Excellent reliability and consistency

Thanks to digital toner HDE and Konica Minolta’s low-temperature fixation technology, AccurioLabel 230 is compatible with a wide range of media including ordinary, matte paper, glossy paper, tack paper and film essential for label production

Download Brochure


− Close All + Expand All
Print Speed A4
23.4m per min.
Warm-up Time
170 sec. or less (with sub-power ON)
Maximum (Original) Document Size [Copy]
90 x 115 to 320 x 1,195mm
System Memory
16,384 MB (standard/max)
System HDD
1 TB × 3 + 500 GB × 1
1,200(w) × 903(d) × 1,478(h) mm (Main body + Original Cover)
Approx. 292kg (Main body only)
Power Consumption
Metric: 6 kW, Inch: 5.76 kW
Print Resolution
3,600 x 1,200 dpi equivalent x 8 bit
Operating System (PCL and XPS) Print
Windows Server2008/R2, Windows7, Windows8.1, Windows Server2012/R2, Windows Server2019, Windows10, Windows Server2016 (Includes 64bit versions) MacOSX 10.9 10.14
Print Controller
Embedded Konica Minolta controller
