Key Features

Up to 81ppm
Monthly page volume
2,400 x 3,600 equiv. dpi x 8-bit
Powerful inline finishing options
Longer paper path
Double sided with duplex printing upto 864mm
High Chroma Toner
The high-chroma toners offer wide colur gamut that reproduce clear and bright colors


− Close All + Expand All
Enhanced productivity

Paper weight for the rated speed is improved from 176gsm to 216gsm. In addition, with the wide paper weight compatibility up to 360gsm, print services including thick paper packages, tags, DMs, sales promotion tools are greatly expanded

Expanded different type of compatibility

By enhancing banner printing and auto duplex banner printing, it helps to differentiate print services from others and allow efficient print work for the production of A4/letter size tri-fold menus, pamphlets and catalogues

Sophisticated media handling

Real time curl correction can be adjusted very precisely in 20 steps. In addition, this not only corrects the curl but also provide an expectation for removal of static electricity, which sustainably contributes to the work efficiency in off-line post processing

Download Brochure


− Close All + Expand All
Print Speed A4
Color: 81 ppm (A4)
1st Copy Out Time A4
Color: 6.1 sec or less; Mono: 4.0 sec or less
Warm-up Time
390 seconds or less
Paper Capacity
15,390 sheets (with main body standard tray + 3 paper feeding units (PF-707m Type C)
Maximum (Original) Document Size [Copy]
100 x 148 – 330.2 x 487.7 mm (up to 1,300 mm with optional Banner Kit)
Output Capacity
Stapling Unit Output: FS-532 (4,200 max)
System Memory
4,096 MB (standard)
System HDD
800 (w) × 903 (d) × 1041 (h) mm (Main body + Original Cover)
Approx. 313 kg (Main body only)
Power Consumption
Metric: Max 6 kW
Print Resolution
S.E.A.D. X 2,400 x 3,600 equiv. dpi x 8bit
Operating System (PCL and XPS) Print
Windows 7, 8.1, 10 (includes 64bit) Windows Server 2008, 2008R2, 2012, 2012R2, 2016
Print Controller
IC-609 (KM), IC-317 ver.3.0 (Fiery), IC-419 ver.3.0 (Fiery)
